ONLY SUPPORT 2G CARD, NOT FIT 3G 4G AND OTHERS. please read below carefully to see if it is available in your country.

Before Order Notice：

Gps bicycle
bicycle tracker
Bug mini
gps tracker bike
bike tracker
bike gps tracker
gps for motorcycle
*Test whether your SIM card is a GSM network
*Send SMS ''000'' to the SIM card and bind the number
*Send SMS ''777'' to the SIM card to get the location

*Send SMS ''102'' to the SIM card to get the device number and password

If GPS replyreceive the messageApp: registering your tracker, please try this order again later!
This means that your card is not on the GSM network (it cannot support GF07), you need to replace it with a GSM card


Item Function:
Suppport GSM band: 850 / 900/1800 / 1900MHZ (2G SIM Card),NOT FIT 3G, 4G or others.
Supporting countries: China/UK/France/Germany/Netherlands/Italy Spain/Portugal/Brazil/Denmark/Russia/Poland /Turkey/Hungary Thailand/Greece/Indonesia/Malaysia/Vietnam/Myanmar/Pakistan /Saudi Arabia/Kazakhstan/Outer Mongolia/Dubai etc,
Not for USA, Australia, New Zealand, Korea, Japan, Canada, Singapore, China Taiwan.


Description:
No matter the alarm locator is placed on the car, in the children's schoolbag, the elderly's pocket, or valuables bags, you can send mobile phone SMS instructions to the alarm locator via your mobile phone to query the location of the alarm locator, which is convenient for you to monitor the whole process and grasp the target in real time.


Appearance size: 3.5cm * 2.0cm * 1.4cm (L * W * H)
Charging input AC110-220V50 / 60Hz
Charging output: DC5.0V 300-500mA
Machine battery: 3.7V 400mAh Li-ion battery
Standby time: 12 days. Working time 4-6 days
Expansion card; mini TF card(not included).
Continuous talk: 150-180 minutes
Network standard: GSM / GPRS
Storage temperature: -40 ° C to + 85 ° C
Working temperature -20 ° Cto + 55 ° C
Humidity range 5% -95% non-condensing
GPRS: Upload 60, TCP / IP
working voltage: 3.4-4.2V DC
standby current :: ≈2.5mA
turn on the sound control current: ≈30mA
talk current: ≈150mA
GSM positioning time: 25 seconds


Package Includes:
1 Piece GPRS Tracking Locator
1 Piece USB Cable


Instructions:
*Preparation: a SIM phone card and a TF memorycard


*Turn on: Open the card cover and insert the SIM card in the direction indicated. After inserting the mini memory card, the product will automatically turn on and the red light will flash 4 times and go out to normal standby after 30 seconds. [Note if you don't read the memory card and insert it again]


*Indicator: The power-on indicator is always on 4 times and the low battery indicator flashes quickly


*bind the master control number; use the mobile phone to edit the SMS 000 and send it to the alarm locator number, and then the machine will reply a short message from the mobile phone; Set; bind + master control number


*Separate recording; use the mobile phone to edit the short message 555 and send it to the alarm locator number, and then the unit will reply a short message to the mobile phone;


*Voice-activated dial-back; use the mobile phone to edit the short message 666 and send it to the alarm locator number, and then the unit will reply a short message to the mobile phone; [DT; Sound monitoring has been successfully set, and the alarm phone is dialed back].


When the sound around the alarm locator is greater than 40 dB, the alarm locator will automatically call the preset mobile phone number.


*GPRS positioning query: Use mobile phone to edit SMS 777 and send it to the alarm locator number. Later, the machine will reply a Chinese geographic location and Map link in the mobile phone. After the mobile phone opens this link, the location map and text address description will appear. Location is more accurate.


*Sound query around the product: Directly dial the number of the card in the alarm locator. After a few seconds, you can hear the sound around the alarm locator (the alarm locator itself will not emit any sound and light during the query).


*Locate track query; use mobile phone to edit SMS 102 and send it to the alarm locator number. Later, the machine will reply a mobile phone with an [account number, password], and log in to the website http;


*Tracking every time; just operate on the computer platform.


* Delete the contents of the memory card; use the mobile phone to edit the short message 445 and send it to the alarm locator number. Later, the machine will reply to the mobile phone with a [TF, the cleaning is successful, the current capacity is available]


*Host status; use mobile phone to edit SMS 888 and send it to the alarm locator number. Later, the machine will reply a text message to the mobile phone; Capacity, etc.].


*Restart the host computer; use the mobile phone to edit the text message 999 and send it to the alarm locator number. Wait for 1 minute to recover successfully.


*Turn off and display the remaining power display stop function on the message; use the mobile phone to edit the text message 444 and send it to the alarm locator number, and then the unit will reply to the mobile phone one, [Reset; all tasks have been cancelled]


*Battery Inquiry: There is battery information in every message you location.


Note:
1. The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness.
2. Please allow slight manual measurement deviation for the data.
